| Engine | |
| Brand | CUMMINS |
| Model | QSF3.8 |
| Type | Water-cooled, 4-stroke, 4-cylinder, direct injection, turbocharged, intercooled, electronic diesel engine |
| Power | 120 HP (90 kW) @ 2200 rpm |
| Maximum Torque | 500 Nm @ 1500 rpm |
| Volume | 3.8 L |
| Emission Class | EU Stage V / U.S. EPA Tier 4 Final |
| BOTTOM CHASSIS | |
| Shoe | 600 mm |
| Number of Shoes | 2×46 adet |
| Number of Walking Rollers | 2×7 adet |
| Number of Carrier Rollers | 2×2 adet |
| Track Tensioner | Hydraulic type and spring cushioned |
| HYDRAULIC SYSTEM | |
| Main Pump | 2 variable displacement, swash plate, axial piston pumps |
| Maximum Flow | 2×126.4 L/dk |
| Pilot Pump | Gear type 20 L/dk |
| Maximum Operating Pressure | 340 Bar |
| GAIT AND BRAKES | |
| Walking | Fully hydrostatic |
| Travel Motor | Variable displacement axial piston motor with 2 speed stages |
| Reduction | 2-stage planetary gear system |
| Walking Speed | 3.2 / 5.3 km/saat |
| Climbability | 35° (%70) |
| Parking Brake | Hydraulic, Disc Type |
| Ground Pressure | 36.8 kPa |
| TOWER ROTATION SYSTEM | |
| Swing Motor | Axial piston motor with swash plate |
| Reduction | 2-stage planetary type |
| Rotation Brake | Disc type, automatic warning |
| Rotation Speed | 11 rpm |
| FILLING CAPACITIES | |
| Fuel Tank | 245 L |
| Hydraulic Tank | 150 L |
| WEIGHT | |
| Operating Weight | |
| Standard Machine Operating Weight | 15.200 kg |
| Dozer Blade | 16.100 kg |
| * 4600 mm boom, 2500 mm arm, 0.6m³ bucket Operating weight includes 75 kg operator and standard equipment machine weight with full fuel tank, hydraulic system and service fluids in accordance with ISO 6016 standard. Optional equipment weights not included. | |
| CABIN | |
| Wide operator viewing angle | ✓ |
| Large interior volume | ✓ |
| Vibration damping 4 siliconized cabin mounts | ✓ |
| High capacity air conditioner | ✓ |
| Color LCD information display | ✓ |
| Cooled glove box | ✓ |
| Cup holder and storage pockets | ✓ |
| Pool type mat | ✓ |
| Suspension seat | ✓ |
| Radio-USB | ✓ |
| Sunshade curtains | ✓ |
| Automatic idling system | ✓ |
| Fully automatic air conditioning | ✓ |
| Reversing camera | ✓ |
| Walking alarm | ✓ |
| FEATURES | |
| 3 different operation 3 different attachment modes | ✓ |
| Multi-language support with on-screen selection | ✓ |
| 0.6 m³ backhoe bucket | ✓ |
| Reversing camera | ✓ |
| Cabin interior security camera | ✓ |
| Automatic idling | ✓ |
| Boom and arm safety valves | ✓ |
| Overheating prevention function | ✓ |
| Automatic power breaker | ✓ |
| Automatic Powerboost feature | ✓ |
| Error and diagnostic log | ✓ |
| Integrated crusher line | ✓ |
| Dozer blade (Optional) | ✓ |
| High capacity LED lighting | ✓ |
| Fuel transfer pump | ✓ |
| PERFORMANCE | |
| Bucket Digging Force (Additional Power) ISO | 100kN |
| Arm Breakout Force (Additional Force) ISO | 76 kN |
| GENERAL DIMENSIONS | |
| Boom | 4600 mm |
| Arm | 2500 mm |
| A- Transport Length | 7825 mm |
| B- Transport Height | 2825 mm |
| C- Transport Width | 2600 mm |
| D- Rear Weight Ground Clearance | 940 mm |
| E- Minimum Floor Clearance | 410 mm |
| F- Rear Weight Turning Radius | 2355 mm |
| G- Length of Pallet on Floor | 3000 mm |
| H- Pallet Length | 3765 mm |
| I- Distance between Pallet Axes | 2000 mm |
| J- Track Clearance | 2600 mm |
| K- Shoe Width | 600 mm |
| L- Cabin Height | 2825 mm |
| WORKING DIMENSIONS | |
| Boom | 4600 mm |
| Arm | 2500 mm |
| a- Maximum Digging Height | 8700 mm |
| b- Maximum Discharge Height | 6200 mm |
| c- Maximum Digging Depth | 5525 mm |
| d- Maximum Digging Depth | 5310 mm |
| e- Maximum Vertical Digging Depth | 5000 mm |
| f- Maximum Reach Distance | 8370 mm |
| g- Maximum Access Distance on the floor | 8225 mm |
| h- Minimum Front Turning Radius | 2645 mm |
